4- TECHNICAL FEATURES
LED Technology
49 FULL COLOUR LEDs (RGBW)
Optical group
WONDER S:
7 x 3.5° lenses; 42 x 8° lenses
3.5° - 52° long excursion high-efficiency linear motorized zoom
22.000 Lux / 5 m
WONDER D:
2 concentric independent high efficiency optical groups
Optical group 1 (7 lenses): 3.5° - 52° long excursion linear motorized zoom
Optical group 2 (42 lenses): 8°- 52° long excursion linear motorized zoom
22.000 Lux / 5 m
Color generation
4 discrete LED areas; each area is independently controllable (luminosity, colors,
effects) 16 million colors each
Wide palette of pure uniform whites with variable linear color temperature (2700K –
8000K)
Interface / Control / Programming
LCD graphic display + 4 soft-keys (control / management of the main parameters)
Long-life auto-charging buffer battery
RDM
ARTNET ready
Wireless ready
Updatable internal operating system
Li-Fe display backup battery (WONDER D)
DMX channels
34 ch (Default) or 38 ch
Pan & Tilt
WONDER S:
Pan 540°: 2.5 sec.; Tilt 270°: 1.5 sec
WONDER D:
‘FPR’ system (D.T.S. patent)
Pan: limitless rotation, in both directions; 360° rotation in 1.56 sec.; Tilt 270°: 1.5 sec.
Tri-phase stepper motor technology for ultra-fast silent movements
16-bit resolution
Selectable speed ranges
Pan / Tilt lock
Power supply
Electronic full-range 90-260Vac 50-60 Hz
Power consumption: 850W
Connection
DMX: 4 XLR connectors (3-pole In and Out; 5-pole In and Out) by Neutrik
Power supply: POWERCON IN and OUT (re-launch) connectors by Neutrik
