Dual CS 418 User Manual

13
Technical Specifications
Motor
Drive
Belt / DC Servo-controlled Motor
Speed settings
33/45/78
Wow & Flutter
< ±0,1 % (DIN WTD)
Tonearm
Bearing
Ball-bearing
Effective length
221,5 mm
Offset Angle
25,6°
Overhang
19 mm
Type
statically balanced with counterweight
Stylus Pressure Range
0 to 4 g
Cartridge Weight Range
5 g to 9 g
Factory installed Pick-up
Ortofon 2M Red
Replacement Stylus
Ortofon Stylus 2M Red
Platter
Material
Aluminium Die-cast
Mat
Rubber 2,5 mm
Bearing
Hardened Steel Spindle, Brass Bushing
Diameter
305 mm
Weight incl. Mat
850 g
Plinth
Surface Finish
Folded MDF Construction with a Black Vinyl Veneer
Feet
Ø 62 mm / Elastomer Damping Element
Connection
RCA socket
Connection to Phono Input
YES
Connection to Line Input
YES
Digital Output
X
Dimension (closed dust cover)
435 x 367 x 145 mm
Dimension (open dust cover)
D: 415 mm / H: 400 mm
Weight
5,8 kg
Power Supply
The efficiency readings were taken with an input Voltage
of 230 V AC at 50 Hz
Type
HK-CS-120A050-CP
Input Voltage
100 bis 240 V AC
Frequency
50 / 60 Hz
Output Voltage
12 V DC
Output Current
0,5 A
Output Watt
6 W
Average Efficiency During Operation
≥ 78,88 %
Power Consumption at Idle
< 0,1 W
