Dual XML8110 User Manual

20
Specifications
Tuningrange: 87.5MHz-107.9MHz
Usablesensitivity: 8.5dBf
50dBquietingsensitivity: 10dBf
Stereoseparation@1kHz: 40dB
Frequencyresponse: 30Hz-13kHz
Tuningrange:530kHz-1710kHz
Usablesensitivity: 22uV
Frequencyresponse: 30Hz-2.2kHz
Operatingvoltage: 11-16 VDC, negative ground
Speakeroutputimpedance: 4~8 ohms
Lineoutputvoltage:2 Volts RMS
Dimensions: 7" x 7" x 2" (178 x 178 x 51 mm)
Designandspecificationssubjecttochangewithoutnotice.
FM Tuner
AM Tuner
General
CEA-2006PowerStandardSpecifications
(reference:14.4VDC+/-0.2V,20Hz~20kHz)
PowerOutput:18WattsRMSx4channelsat4ohmsand<1%THD+N
SignaltoNoiseRatio:80dBA(reference:1wattinto4ohms)
XML8110 OPERATION

Dual XML8110 Specifications

General

Brand	Dual
Model	XML8110
Category	Docking Station
Language	English
