Ducane 04 Series - Page 39

FIG. 33
MAIN GRILLING BURNER AND ROTIS BURNER
PROPER BURNER ORIFICE ENGAGEMENT
BURNER
ELECTRODE WIRE
ELECTRODE
COLLECTOR BOX
(ROTARY IGNITION MODELS,
EXCEPT 800 SERIES)
SHUTTER
VALVE
ORIFICE
NICHROME
GLOW WIRE
SHUTTER
LOCKING
SCREW
CENTER LINE
OF PORTS
ELECTRODE
A ROTIS-A-GRATE
®
BURNER SUPPORT
ROTIS-A-GRATE
®
BURNER
ELECTRODE WIRE
FIG. 32
CHECK AND, IF NECESSARY, ADJUST SPARK GAP OF ROTIS-A-GRATE
®
ELECTRODE AS SHOWN AFTER ROTIS BURNER IS REINSTALLED.
1/8" – 3/16"
38
02/33
