37
1. Feed the electrode wire through the hole in the
bottom of the burner box while sliding the main
burners through the front of the burner box. Be
sure the burner shutter engages over the valve
orifice. (See Fig. 33)
2. The strap on the burners must
sit in the mounting
support built into the bottom of the burner box.
3. The electrode wire must be able to slide out from
under the burner box and attached to one of the
ignitor studs.
4. Each burner must be locked in place using one
screw previously removed.
5. Feed the rotis electrode wire into the burner box
hole while sliding it through the front of the
burner box. Be sure the burner shutter engages
over the valve orifice. (See Fig. 33)
6. Line up the holes in the rotis burner bracket with
the holes in the back of the burner box. Lock the
burner in place using the two screws and two
acorn nuts previously removed.
7. Reconnect the electrode wire to the ignitor after
bringing it out from under the burner box.
8. Put the ROTIS-A-GRATE
®
into position,
being sure the tabs on the back lock over
the back edge of burner box. (See Fig. 35)
WARNING:
Check that each burner is properly
engaged over the orifice. Failure to ensure proper
burner/orifice engagement could lead to a fire,
explosion and/or bodily harm.
9. Place the LA-VA-GRATE
®
on the front supports
in the burner box and lower (holding flange
with arrow) onto the ROTIS-A-GRATE
®
shelf.
(See Fig. 34)
10. Place, do not dump, one layer of briquettes to
cover entire surface of LA-VA-GRATE
®
. See Page 8
for instructions.
11. Replace SEAR GRID
®
. (See Fig. 35)
Preserve Your Console or Cabinet
Your cabinet or console parts are made from a
pre-painted galv-alum (coated steel) material or
stainless steel. To retard rust, it is recommended that
you apply a coat of car wax to your console or cabinet.
By following this suggestion, you will be extending the
life of your gas grill. Remember, your console should
be treated the same as you would your automobile
finish. By periodically waxing (liquid spray car wax
will do) your console, you will be extending the life
of your Ducane gas grill.
Although we take great precautions to inhibit rust
on your cabinet, many outside factors such as high
humidity, chlorine (especially in concentrations such
as around a pool, industrial fumes and salt air) can
render these precautions ineffective. For this reason,
rust (painted panels) is not covered by the Limited Five
Year Warranty unless it affects the structural integrity of
the console base.
Preserve Your Control Box
Your Ducane grill is equipped with a stainless steel
control box wrapper. To keep the stainless steel looking
its best is a simple matter. Clean it with soap and water,
rinse with clear water and wipe dry. It’s that easy.
We recommend the use of a diluted liquid
dishwashing detergent and water solution.
10. Reinstallation of the Main and
ROTIS-A-GRATE
®
Burners
Remember to follow all of the preceding
90-day maintenance tips and the life of your grill
will be extended.
To reinstall Main Grilling Burner(s), ROTIS
BURNER
®
, LA-VA-GRATE
®
, briquettes and SEAR GRID
®
,
follow Steps 1 Thru 11.
