Ducar DT36V - Specifications

23
12. Specifications
CONTENT
Model DT36V
Dimension (L*W*H) 705*375*660
N.W(kg) 30
Transmission system Worm and gear
Clutch type Belt tensioned clutch
Tilling scope(mm) 360
Tilling depth(mm) 260
Left handlebar(m/s2) 13
Right handlebar(m/s2) 13
Uncertainty K 2
Workstation sound pressure level (dB(A))
74
Guaranteed sound power level (dB(A))
93
Measurement uncertainty K 2
Gear shifting NA
Model DVO160
Type
1‐cylinder, 4stroke,OHV, forced air
cooling
Bore X stroke(mm) 65 x 48.5
Displacement(cm³)
161
Rated power (kW/min
‐1
) 2.9/3600
Max. .torque (N.m/min
‐1) 8.5/2800
Ignition system Transistor Magneto
Starting system Recoil start
Fuel tank capacity(L) 1.3
Oil Capacity (L) 0.35
Vibration
Noise
ENGINE
TILLER
ITEM
