Ducati 748 - Left Switch

14
E
Left switch
1) Switch, light switch, 3 positions:
Down = light off;
Centre = front and rear parking light, number plate
light and panel lights on;
Up = headlamp, front and rear parking light, number
plate light and panel lights on.
Note
This device is not fitted on the Australia and Japan
versions.
2) Dip switch, light dip switch, two positions:
position = low beam on;
position = high beam on.
3) Switch = 3-position turn indicator:
centre position = off;
position = left turn;
position = right turn.
To disable turn indicators, return switch to central
position and push in.
4) Button = warning horn.
5) Button = passing.
4
2
3
1
5
fig. 7
4
2
3
1
5
fig. 8
748/748S
998
