Throttle cable adjustment
The throttle twistgrip must have a free play of 1.5-2 mm
measured at the edge of the twistgrip, at all positions of
the handlebars. If it needs adjusting, use the suitable
adjuster (2, fig. 49) provided on the throttle control.
1,5 ÷ 2 mm
2
1
fig. 49
Charging the battery (fig. 50 and 51)
Before charging the battery, it is best to remove it from
the motorcycle.
Remove the r.h. body panel (page 40), undo the screw (1)
and remove the upper bracket.
Always disconnect the black negative terminal (-) first,
and then the red positive terminal (+).
Warning
Batteries develop explosive gases: keep it away
from heat sources and flames.
Charge the battery in a ventilated room.
Connect the battery charger leads to the battery
terminals - red to positive terminal (+), black to negative
terminal (-).
+
1
-
fig. 50
