Closing (fig. 21)
Pull gently the tail guard outwards and lower it to its
horizontal position. Press on the passenger pillion to
allow the clips (3) – integral with the fairing - to catch the
pins (4) – integral with the frame, until you hear the catch
click.
Pull the tail guard gently up to make sure it is firmly
secured to the frame.
fig. 21
