Ducati 748 - Page 72

748
748S
72
E
Legend of fuse box (4)
Pos. Description Rat.
A-1 Main switch 30 A
B-2 Cooling electric fan 7.5 A
C-3 Left switch 3 A
D-4 High beam 15 A
E-5 Low beam 15 A
F-6 Turn indicators, warning lights, 7.5 A
parking lights and instrument panel
lights
G-7 Stop, warning horn 7.5 A
H-8 Right switch 3 A
Wire color coding
P Pink
G Green
W White
O Orange
Y Yellow
B Blue
Bn Brown
R Red
V Violet
Gr Grey
Lb Light blue
Bk Black
