Ducati 749 2003 - Running-In and Pre-Ride Safety Checks

40
E
STANDARD factory setting is as follows:
compression: 8 clicks;
rebound: 8 clicks.
To change the preload of the spring inside each fork leg,
turn the hex. adjusting nut (2) with a 22-mm hexagon
wrench.
Preload setting range (A, fig. 37) is from 25 to 10 mm.
Factory setting is 20 mm.
Important
Adjust both fork legs to same settings.
A
2
1
3
fig. 37
fig. 38
