Wire color coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Legend of fuse boxes (fig. 82 and 83)
Pos. Description Rtng.
1A High and low beams 15 A
1B Stop light – horn – flasher - 20 A
starter contactor
1C Key on 7.5 A
1D Instrument panel power supply 3 A
2E Engine control unit 3 A
2F Injection relay 20 A
Note
The system wiring diagram is at the end of this
manual.
