Headlamp fairing
Note
The rear-view mirrors and side body panels must
first be removed as described above to allow removal of
the headlamp fairing.
Pull the instrument panel (1) until clear of the rubber
grommets (2) and disconnect the connector (3) at the
main wiring harness end.
Disconnect the connectors of the parking light bulb.
Unscrew the two screws (4) that secure the headlamp
fairing to the headlamp support at either side.
Note
After refitting the headlamp fairing, refit the side
body panels and the rear-view mirrors.
