Ducati MONSTER 696 User Manual

Note
When the motorcycle is left unused
(approximately for more than 30 days) we
recommend owners to use the Ducati battery charge
maintainer (Battery maintainer kit part no. 69924601A
- various countries; Battery maintainer kit part no.
69924601AX - for Japan, China and Australia only) ;
since its electronics monitors the battery voltage and
features a maximum charge current of 1.5 Ah.
Connect the maintainer to the diagnostics socket
located in the tail of the bike.
Note
Using charge maintainers not approved by
Ducati could damage the electric system; vehicle
warranty does not cover the battery if damaged due
to failure to comply with the above indications, since
it is considered as wrong maintenance.
112

Ducati MONSTER 696 Specifications

General

Displacement	696 cc
Bore x Stroke	88 x 57.2mm
Compression Ratio	10.7:1
Power	80 hp (59 kW) @ 9000 rpm
Transmission	6-speed
Frame	Tubular steel Trellis frame
Front Brake	2 x 320 mm discs, 4-piston radial calipers
Rear Brake	245 mm disc, 2-piston caliper
Seat Height	770mm (30.3 in)
Engine Type	L-Twin, 2 valves per cylinder Desmodromic
Torque	69 Nm (51 lb-ft) @ 7750 rpm
Fuel System	Electronic fuel injection, 45 mm throttle body
Exhaust	2-1-2 system with catalytic converter and lambda probe
Front Suspension	43 mm upside-down forks
Rear Suspension	Progressive with preload and rebound adjustable monoshock
Dry Weight	161 kg (355 lb)
Fuel Capacity	15 L (3.9 US gal)
