Ducati MONSTER 696 - Left-Hand Switch

Left-hand switch
1) Dip switch, two-position light selector switch:
position
= low beam on;
position = high beam on.
2) Switch = three-position turn indicator:
centre position = off;
position = left turn;
position = right turn.
To cancel the turn signal, press the lever once it
has returned to the central position.
3) Button = warning horn.
4) Button = high beam flasher.
5) Two-position instrument panel control switch:
position “ ”;
position “ ”.
4
1 2 3
5
Fig. 38
74
