The main fuse box (9) is located on the right side of
the frame.
Remove the protective cover (A) to access the fuses.
In addition to the fuse box, the two ABS fuses (10)
are located near the regulator fuse.
10A
15A
15A
15A
20A
20A
5A
5A
A 97 8
1 2 3 4 5 6
Fig. 118
11
696
Fig. 119
163
