Duke TSC-6/18 Service Manual

Service Manual for Proofer Oven with Touch Screen Controls (TSC)
38
TSC OVEN LINE SUPPLY WIRING
L1
L2
L3
N
BLACK wire labeled “1”
BLACK wire labeled “1A”
RED wire labeled “2”
RED wire labeled “2A”
WHITE wire labeled “3”
WHITE wire labeled “3C”
Not
Used
L1
L2
N
Not
Used
LINE SUPPLY:
3 Phase 208V
or 3 Phase 240V
L1 to L2 - 208V / 240V
L1 to L3 - 208V / 240V
L2 to L3 - 208V / 240V
L1 to N - 120V
L2 to N - 120V
L3 to N - 120V
N (neutral) not used
Terminal Block
Connection:
3 Phase
Terminal Block
Connection:
Single Phase
Oven Contactor
Connection:
3 Phase
Oven Contactor
Connection:
Single Phase
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
L1
L2
L3
N
BLACK wire labeled “1”
BLACK wire labeled “1A”
RED wire labeled “2”
RED wire labeled “2A”
WHITE wire labeled “3”
WHITE wire labeled “3C”
BLACK wire labeled “1”
BLACK wire labeled “1A”
RED wire labeled “2”
RED wire labeled “2A”
WHITE wire labeled “3”
WHITE wire labeled “3C”
LINE SUPPLY:
Single Phase 208V
or Single Phase 240V
L1 to L2 - 208V / 240V
L1 to N - 120V
L2 to N - 120V
N (neutral) not used
European Only
Terminal Block
Connection:
400V 3P w/N
LINE SUPPLY:
3 Phase 400V 50Hz
(International ONLY)
L1 to L2 - 400V
L1 to L3 - 400V
L2 to L3 - 400V
L1 to N - 230V
L2 to N - 230V
L3 to N - 230V
BLACK wire labeled “31”
BLACK wire labeled “1”
RED wire labeled “2”
WHITE wire labeled “3”
RED wire labeled “32”
WHITE wire labeled “31”
WHITE wire labeled “32”
BLACK wire labeled “31”
BLACK wire labeled “1”
RED wire labeled “2”
WHITE wire labeled “3”
RED wire labeled “32”
WHITE wire labeled “32”
WHITE wire labeled “31”
