Problem Possible Cause Corrective Action
When ignitor button is
pressed in, there is no
spark at ODS/pilot
1. Low battery.
2. Ignitor electrode is not
connected to ignitor cable.
3. Ignitor cable is pinched or
wet.
4. Ignitor electrode is positioned
wrong. Ignitor electrode is
broken.
5. Broken ignitor cable.
6. Bad ignitor.
1. Replace battery.
2. Replace ignitor cable
3. Free ignitor cable if pinched
by any metal or tubing. Keep
ignitor cable dry.
4. Replace electrode.
5. Replace ignitor cable.
6. Replace ignitor.
When ignitor button is
pressed in there is a
spark at ODS/pilot but no
pilot ame present.
1. Gas supply is turned o󰀨 or
equipment shuto󰀨 valve is
closed.
2. Control knob not in PILOT
position.
3. Control knob not fully
pressed in while pressing
ignitor button.
4. Air in gas lines (new
installation or recent gas
interruption).
5. ODS / pilot is clogged.
6. Incorrect inlet gas pressure
or inlet regulator is damaged.
7. Depleted gas supply
(propane).
1. Turn on gas supply or open
equipment shuto󰀨 valve.
2. Turn control knob to PILOT
position.
3. Fully press in control knob
while pressing ignitor button.
4. Continue holding down
control knob. Repeat igniting
operation until air is removed.
5. Clean ODS/pilot (see Care
and Maintenance, page 26) or
replace ODS/pilot assembly.
6. Check inlet gas pressure or
replace inlet gas regulator.
7. Contact local propane gas
company.
ODS/pilot lights but ame
goes out when control
knob is released.
1. Control knob is not fully
pressed in.
2. Control knob is not pressed
in long enough.
3. Equipment shuto󰀨 valve is
not fully open.
4. Thermocouple connection is
loose at control valve.
5. Pilot flame not touching
thermocouple, which allows
thermocouple to cool, caus-
ing pilot ame to go out. This
problem could be caused by
one or both of the following:
A) Low gas pressure
B) Dirty or partially clogged
ODS/pilot
6. Thermocouple damaged.
7. Control valve damaged.
1. Press in control knob fully.
2. After ODS/pilot lights, keep
control knob pressed in 30
seconds.
3. Fully open equipment shuto󰀨
valve.
4. Hand tighten until snug, and
then tighten 1/4 turn more.
5. A) Contact local natural or
propane gas company
B) Clean ODS/pilot (see
Care and Maintenance,
page 26) or replace ODS/
pilot assembly
6. Replace thermocouple.
7. Contact customer service.
TROUBLESHOOTING
The entire gas delivery piping including connec-
tions inside the heater should be leak tested by
the qualied installer. After leak testing the quali-
ed installer should light the appliance. Refer to
the correct ame pattern as illustrated on page
22. All ame patterns should be safely inside the
product. If for any reason they are not, stop use
of the appliance and call for repairs.
