Dunster House Monkey bars - Assembly: Horizontal Ladder - Swing Beam

Assembly Instructions
STEP -
HORIZONTAL LADDER - MONKEY BARS - SWING BEAM (1S)
1
Page 10
Required Components
C40651B - 86x86x2400 (1x)
2
4
0
0
C40558A - 86x43x2400 (1x)
2
4
0
0
C4038A - 44x44x550 (7x)
5
5
0
SCREWS
30x 50mm
SWING BRACKET
PACK (2x)
of
1
Horizontal Ladder - Swing Beam (1S)
1
3
2
Direction of
grooves
on rungs
C40651B - 86x86x2400
Swing Brackets
C4038A - 44x44x550 (7x)
C40558A - 86x43x2400
Push Together
Note:
Pre-drill all screw holes with a 3mm drill bit.
9
4
3
9
4
3
Note:
• When pre-drilling, do not drill through the rungs.
• Secure with screws as shown.
Note:
• In order to comply with safety regulations please
ensure these dimensions are met.
Note:
• Lay components in position on the ground
before fixing.
Note:
• Please ensure that rungs are placed
with grooves in the correct direction.
Section view showing orientation of
rung in monkey bar ladder.
50mm Screws (28x)
M5x10mm Washer (2x)
50mm Screws (2x)
M5x10mm
WASHER (2x)
