DB1200
Marketed by Wal-Mart Stores, Inc.
Bentonville, AR 72716
Shop at Walmart.com
Printed in China
DB0305-V02
DB1200 SPECIFICATIONS
Specifications
Frequency response: 20Hz-20kHz
Channel separation @ 1kHz: >65dB
D/A converter: 1 Bit
Tuning range: 87.5MHz-107.9MHz
Usable sensitivity: 12dBf
50dB quieting sensitivity: 16dBf
Stereo separation @ 1kHz: 40dB
Frequency response: 30Hz-13kHz
Tuning range: 530kHz-1710kHz
Usable sensitivity: 30uV
Frequency response: 80Hz-2kHz
Peak power output: 15 watts x 4
Power output per CEA-2006 standard
5 watts RMS x 4
(measured at 4 ohms, 14.4 VDC, <
1% THD+N)
Signal-to-Noise Ratio: 75 dBA
(reference: 1 watt into 4 ohms)
Operating voltage: 11-16 VDC, negative ground
Speaker output impedance: 4~8 ohms
Fuse: 5 amp AGC
Dimensions: 7" x 7" x 2" (178 x 178 x 51 mm)
Design and specifications subject to change without notice.
CD Player
FM Tuner
AM Tuner
General
