6
Now check that all the control surfaces move in the correct direction with the correct stick input
(see above).
Aileron Elevator Rudder
One other thing to check before setting
up is that the control linkages are in
the correct holes on the horns.
To the left is a picture of the
recommended positions for each
control surface at the servo end, and
at the surface control horn end.
Factory Setting Horns Arms
Elevator
Rudder
Aileron
Ailerons Left
Ailerons Right
Elevator Up
Elevator Down
Rudder Left
Rudder Right
