32
EAN-128, UPC-A, UPC-E, EAN and UPC2(5) digits
add-on, MSI, PLESSEY, POSTNET, ChinaPOST,
ITF-14, EAN-14.
2D Bar code
PDF-417, Maxicode, and DataMatrix, QR CODE.
Command Set TSPL2
Environment
Operation
Temperature: 5℃ ~ 40℃.
Relative Humidity: 25% ~ 85% (Non Condensing).
Storage
Temperature: -40℃ ~ 60℃.
Relative Humidity: 10% ~ 90% (Non Condensing).
7.2 Label Stock Specifications
Item Specification
Type Label (Continuous , Die-cut , Fan-fold).
Wound Type Outside wound.
Width 20mm ~ 112mm (0.78” ~ 4.4”).
Length 10mm ~ 1000mm (0.4” ~ 39”).
25.4mm ~ 1000mm (1” ~ 39”).(for peeler and cutter)
Thickness 0.06mm ~ 0.19mm. (2.3~7.4 mil), max. 150g/m
2
Roll Diameter 5”.
Roll Core Diameter 25.4mm ~ 76.2mm (1” ~ 3”).
Gap Height 2mm min.
Black Mark Height 2mm min.
Black Mark Width 8mm min.
7.3 Ribbon Specifications
Item Specification
Type Wax, Wax / Resin, Resin.
Core Diameter 1".
Width Max 110mm.
Capacity 300m with 1" core.
Wound Type Outside wound.
Ribbon End Clear or silver end tape.
