5
RECEIVER ANTENNA INSTALLATION
6-CELL BATTERY INSTALLATION
• Route the receiver antenna wire
through the receiver antenna tube.
• Insert the antenna tube into the molded
antenna mount on the battery strap.
• Install the antenna tube cap onto the
top of the antenna tube.
• DO NOT cut or coil the receiver
antenna wire.
• Remove the body clip from the battery strap post.
• Remove the battery strap.
• Install a 7.2V battery into the chassis.
• Reinstall the battery strap and secure it in place
with the body clip.
• Check that the ESC is “OFF,” and then plug the
battery into the ESC.
RED
7.2V BATTERY
DO NOT CUT THE
ANTENNA WIRE!
