DURKOPP ADLER DAC basic Operating Manual

Operating manual part II
II-22 © 2013 Dürkopp Adler AG
Level
Code
Error description
Corrective
- Check the thread lever up position (Position 2)
Error 3100 AC RDY timeout , intermediate circuit
voltage has not reached the defined
threshold in the given time.
- Check mains voltage
- If mains voltage OK, replace control unit
Error 3101 High voltage error, mains voltage
>290V for some time
- Check mains voltage, if rated voltage exceeded
permanently - stabilise or use generator
Error 3102 Low voltage failure (2nd threshold)
(mains voltage < 150V AC)
- Check mains voltage
- Stabilise mains voltage
- Use generator
Information
3103 Low voltage warning (1st threshold)
(mains voltage < 180V AC)
- Check mains voltage
- Stabilise mains voltage
- Use generator
Warning 3104 Pedal position is not at position 0 When switching on the control unit, take foot off pedal
Error 3105 Short circuit U24V - 37 pin Take plug out, if error 3105 continues, replace
control unit
- Test inputs/ outputs for 24V short circuit
Error 3106 Overload U24V (I²T) - one or more of the magnets faulty
Error 3107 Pedal not connected - connect analogue pedal
Information
3108 Speed limiting because the power
supply is to low
- check your power supply
Warning 3109 Maintaining safety - Check the tipping sensor on the machine
Information
3150 Maintenance required (info) - For information on lubricating the machine see the
machine's service instructions
Warning 3151 Maintenance requir
ed (continue only
when parameters reset
t 51 14, see machine's operating
instructions)
-
carry out service urgently, see machine's service
instructions
Information
3215
Bobbin thread ounter (info value 0
reached)
- Change reel, set counter value - press counter reset
button
Information
3216 Bobbin thread monitor left - Change left bobbin
Information
3217 Bobbin thread monitor right - Change right bobbin
Information
3218 Bobbin thread monitor left and right - Change left and right bobbin
Error 6353 Internal EEprom communication error - Switch off control unit, wait until the LEDs go out and
turn on again.
Error 6354 External EEprom communication error - Switch off control unit, wait until the LEDs go out and
check the connection of the mach-ID. Turn the control
on.
Information
6360 No valid data on external EEprom - Update software. The internal data structures are not
compatible with the external data memory
Information
6361 No external Eeprom connected - Plug in mach ID
Information
6362 No valid data on internal EEprom - Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The internal data structures are not
compatible with the external data memory
Information
6363 No valid data on internal or external
EEprom
(only emergency run features)
- Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The software version is not
compatible with the internal data memory
Information
6364 No valid data on internal EEprom and
external EEprom not connected
(only emergency run features)
- Check connection mach-ID
- Switch off control unit, wait until the LEDs go out and
turn on again.
- Update software. The internal data structures are not
compatible with the external data memory
Information
6365 Internal EEprom faulty - Replace control unit
Information
6366 Internal EEprom faulty and external - Replace control unit
