DURKOPP ADLER DAC basic Operating Manual

Operating manual part II
© 2013 Dürkopp Adler AG II-5
1.1.2 Technician-level
The technician's level must not be accessed by normal users. Modifications at this level must only be done by service
staff.
The technician's level is unlocked by the following key combination:
When switching on the control unit P (23)and the reset (18) button must be pressed at the same time.
This allows access to the technician's level.
Press A+ to get into the technician's level.
L C P Min Max Preset Unity Description
Backtack
t 00 00 300 6000 800 rpm Start backtack speed
t 00 01 0 254 8 10° Pre-control angle when switching on the backtack magnet.
(Switchover of forward backward at the bartack)
t
00 02 0 254 12 10° Pre-control angle when turning the backtack magnet off.
(Changing of backward forward at the bartack)
t 00 03 0 1 0 - Start backtack with the position 0 of the pedal interruptible.
0 = off;
1 = on
t 00 04 0 2 0 - Mode for the end of the start backtack.
0 = You sew further after the end;
1 = Machine stops and must be started by the pedal again;
2 = Thread performance after the start backtack
t 00 05 0 1 1 - Pedal release only to an additional route A
0 = off;
1 = on
t 00 06 0 500 0 ms Delay time up to the speed release after the start backtack
t 00 07 0 255 0 ms Decay time of the backtack magnet
t 00 10 300 6000 800 rpm End backtack speed
t 00 11 0 254 12 10° Pre-control angle when switching on the backtack magnet.
(Switchover of forward backward at the bartack)
t 00 12 0 254 13 10° Pre-control angle when turning the backtack magnet off.
(Changing of backward forward at the bartack)
t 00 13 0 1 0 - Backtack magnet stays switched on (simple with the last
backward way final backtack and multiple backtack ends) till
the needle has been reached the Pos. 2.
0 = off;
1 = on
t 00 20 300 6000 800 rpm Start multiple backtack speed (only at the stuffing program)
t 00 21 0 254 16 10° Pre-control angle when switching on the backtack magnet.
(Switchover of forward backward at the backtack) (only at the
stuffing program)
t 00 22 0 254 22 10° Pre-control angle when turning the backtack magnet off.
(Change of backward forward at the backtack) (only at the
stuffing program)
t 00 23 0 1 0 - Start backtack as a stuffing program.
0 = off;
1 = on
t 00 30 0 1 0 - Ornamental backtack
0 = off;
1 = on
t 00 31 0 2500 800 rpm Ornamental backtack speed
t 00 32 0 1000 150 ms Stop time at the ornamental backtack
t 00 35 0 1 1 - Reducing speed when shifting the feed dog
0 = off;
1 = on
