PART II
1 Parameter
The parameter overview is help a sought-after parameter for finding fast and changing. The construction of the list
has already been explained in the list using structure.
There are parameters, which can be found in the technicians' and developers' level both different consequences,
however, have. All settings in the developers' level aren't accessible for using staff and service technicians but are
adjusted by the software developers to the certain hardware once.
1.1 Parameter of class 838
class:
838
t 51 04 set of parameters:
838-x70522-1,55
for sub-class:
838-170522-1,55,
838-270522-1,55
1.1.1 Operator-level
L C P Min Max Preset Unity Description
Bobbin thread counter and bobbin thread monitor
o 06 00 0 4 0 - Activate the bobbin thread counter
0 = off;
1 = Bobbin thread counter A;
2 = Bobbin thread counter B;
3 = Bobbin thread counter C;
4 = Bobbin thread monitor
o 06 01 0,1 999,9 300,0 x o0602
Reset value of the bobbin thread counter A
o 06 02 0,1 999,9 200,0 x o0604
Reset value of the bobbin thread counter B
o 06 03 0,1 999,9 100,0 x o0604
Reset value of the bobbin thread counter C
o 06 04 1 255 10 x stitches Factor of the bobbin thread counter A, B, and C
o 06 05 0 9999 0 stitches
Number of stitches for bobbin thread monitor
o 06 06 0 1 1 - Stopping motor if the counter has reached the value 0.
0 = off;
1 = on
o 06 07 0 1 1 - Sewing foot down after thread trimming.
0 = off;
1 = on
o 06 08 0 1 0 - Display of the bobbin thread counter value
0 = off;
1 = on
Needle cooling
o 13 00 0 1 0 - Needle cooling
0 = off;
1 = on
Light barrier
o 16 00 0 255 0 Stitches Compensating stitches normal stitch length
o 16 01 0 255 0 Stitches Compensating stitches long stitch length
o 16 10 0 255 0 Seams Number of light barrier seams
o 16 20 0 255 0 Stitches Number of stitches of the filter for knitted fabrics
