27
Item Part Qty Description Item Part Qty Description
1 DJ188F-16121-C 1 Starter comp, recoil 43 DJ190FD-14100-A 1 Carburetor assy.
2 GBT5789-B6-8 3
Flange bolt M6×8
44 DJ188F-14003-B 1 Packing, carburetor
3 DJ188F-16120-A 1 Fan, cover comp 45 DJ188FD-14004-A 1 Insulator, carburetor
4 GBT5789-B6-12 13
Flange bolt M6×12
46 GBT6177/10-N-6 2 Flange nut M6
5 DJ188F-11012-A 1 Shroud comp 47 DF6500H-14205-A 1 Stay, air cleaner
6 DJ168F-11039-A 3 Clip. Wire darkness 48 DJ188FD-14203-A 1 Case comp, air cleaner
7 DJ168F-16118-A 1 Grommet drain hole 49 DJ188FD-14202-A 1 Retainer Filter Element
8 DJ188F-18600-A 1 Start motor 50 GB/T6177-2000 6 Flange nut M5
9 GBT16674 2
Flange bolt M8×35
51 DJ188FD-14204-A 1 Cover comp, air cleaner
10 GBT6177-N-14 1 Flange nut M14 52 DJ188FD-14207-A 2 Clip, air cleaner ware
11 DJ188F-16000-A 1 Pulley, starter 53 DJ188FD-14201-A 1 Element, air cleaner
12 DJ188F-16002-A 1 Fan, cooling 54 DJ188FD-14206-A 1 Seal, air cleaner
13 DJ168F-12104-A 1 Key 55 DJ188F-14005-A 1 Packing, insulator
14 DJ188F-16200-G 1 Flywheel comp 56 14601 4 Clip, tube
15 DJ188F-11014-A 2
Oil seal, 35×52×8
57 14013 1 Valve, dashpot check assy.
16 DJ190F-11100-D 1 Crank case assy. 58 14034 1
Tube, fuel φ45×165
17 DJ168F-18300-A 1 Amplifier 59 DJ188FD-11013-A 1 Tube, breather
18 DJ188F-11004-A 2 Bolt, drain lug 60 GBT5787-B10-80 4
Flange bolt M10×80
19 DJ188F-11005-A 2 Washer, drain lug 61 DJ188F-11200-B 1 Head comp, cylinder
20 DF2500H-34118-A 1 Clip, wire 62 DJ188F-14002-A 2
Bolt head, M8×48
21 34218-001 1 Idle Control Component 63 DJ168F-18500-A 1 Plug, spark
22 GBT5789-B6-25 2
Flange bolt M6×25
64 DJ190F-13100-C 1 Camshaft assy.
23 DJ188FB-18106-A 1 Cord stop switch 65 DJ190F-13009-A 2 Lifter, valve
24 DJ188F-11017-A 1 Grommet cord 66 DJ188F-13001-A 1 Valve, IN.
25 DJ188F-18100-C 1 Coil assy. ignition 67 DJ188F-13002-A 1 Valve, EX.
26 DJ188F-15009-A
Oil seal, Φ8×φ14×5
68 DJ188F-13011-A 1 Seat, valve spring
27 DJ188F-11014-A 2
Oil seal,Φ 35×Φ52×8
69 DJ188F-13005-A 1 Retainer, EX. Valve spring
28 DJ188F-15001-A 1 Shaft, governor arm 70 DJ188F-13006-A 1 Rotator, valve
29 DJ188F-15003-A 1 Pin, lock 71 DJ188F-13004-A 1 Retainer, IN. Valve spring
30 DJ188F-15002-A 1
Washer, Φ8×1
72 DJ188F-13003-A 2 Spring, valve
31 GB/T6177-2000 1 Flange nut M10 73 DJ190F-13008-A 2 Rod, push
32 DJ188F-18202-A 1 O-ring,14mm 74 DJ188F-11011-A 1 Exhaust piper
33 DJ188F-18200-A 1 Oil Sensor 75 DJ188F-11300-B 1 Cover comp, head
34 DJ188F-12004-A 1 Balancing Shaft 76 DJ188F-11016-A 1 Washer comp head cover
35 DJ190F-12100-BB 1 Crankshaft comp 77 DJ188F-11015-A 1 Bolt, head cover
36 GB276-89-6207 2 Radial ball bearing (6207) 78 GBT6175-N-8 2 Nut M8
37 DJ188F-11009-A 2
Pin, dowel, 12×20
79 DJ188FD-14009-B 1 Pipe comp EX.
38 DJ190F-11010-C 1 Casket, cylinder head 80 DJ188FD-14010-A 1 Casket (B) EX. Pipe
39 DJ188FD-14001-A 2
Bolt head, 8×106
81 DJ188F-13300-A 1 Plate, push rod guide
40
DJ188F-14027-A
2
Gasket,Air Cleaner
82 DJ188F-13202-A 2 Bolt, pivot
41 DJ188F-14012-A 1 Stay assy. Manual choke 83 DJ188F-13201-A 2 Arm, valve rocker
42 DJ188F-14501 1 Grommet fender 84 DJ168F-13203-A 2 Nut, Arm, valve rocker
