Page 3
Parts checklist
Please check you have all the parts listed below with your product:
Do not discard any of the packaging until you have checked that you have all the parts and the pack of fixings.
0 1 2 3 4 5 6 7 8 9 1010 11 12 13 14 15 16 17 18 19cm
Bolt Length Ruler:
Fittings checklist
Please check you have all the fittings listed below with your product:
M6 x 33mm Bolt x4pcs M6 Allen Key x1pc
A B C
15mm Washer x4pcs
Plastic Bracket x4pcs 37mm Wall Plug x4pcsD
F
E M3x20mm Screw x4pcs
M3x40mm Screw x4pcs
G H 250mm Nylon Strap x2pcs
Crosshead Screwdriver (not provided)
Tool required
3 120mm Handle x8pcs
(Handles are pre-attached
inside of the drawers)
1 5 Drawer Chest x1pc 2 240mm Leg x4pcs
