RING YOKE SUB-ASSEMBLY PARTS
Item Qty. Description Part Number
121 1 Ring Yoke B4-088-0007
122 2 Bushing, Ring Yoke P4-909-0017
123 2 Ring Arm B4-091-0125
124 2 Bushing, Ring Yoke A4-024-0048
125 2 Flat Hd. Socket Cap Screw 13-E-0510
127 2 Bushing, Ring Lever P4-909-0021
128 1 Ring Lever B4-045-0030
129 1 Drive Pin 75-D-0824
130 2 Pivot Bolts A4-033-0010
1 Ring - Nylon (Not Shown) B4-095-0079
RING YOKE SUB-ASSEMBLY DRAWING
25
