Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141-1- Hydraulic tank Edition: 1.2009
Pos. No. Quantity
Designation Part no. Comment
1 2 Hexagon screw M8x25 A4 DIN 933 2426246
2 2 Spring disk M8 A4 DIN127 2538047
3 2 Washer M8 A4 DIN 125 2537047
4 1 Return filter SIF 20 C10 2251064
Filter element for SIF.20C10 2251065 Service part
5 1 Hexagon nipple 1” L-22mm 2957781
6 1 T-hexagon nipple L22L22L22/S 2957778
7 1 Filling cap (complete) 2931018
8 1 Hexagon nipple GEK BSP 1/4” L10 ED 2957754
9 1 Hexagon nipple GEK BSP 1/2” L15 ED 2957768
10 1 Flash fittings 8mm ¼” straight 2957818
11 1 Reducer L22-L15 2957512
12 1 Hexagon nipple GEK BSP 1/2” L12 ED 2957766
13 1 Sight glass with thermometer 2957820 to:09015
13 1 Sight glass M12 L-76 2957821 From:09016
14 1 Thermometer 2957825 From:09016
15 1 Main tank 14120148 to:09015
15 1 Main tank 14120223 From:09016 to :09085
15 1 Main tank 14120242 From:09086
16 4 Hexagon nut M10 locking galvanized 8.8 2483610
17 4 Washer M10 galvanized 2531060
18 4 Locking screw M10x25 galvanized 8.8. 2344330
19 2 Hexagon nipple GEK BSP 3/4” L22 ED 2957774
20 2 Hydraulic seal ½” 2957861
21 1 Ball valve ½ - ½” 2957602 To:09085
21 1 Valve 1/2" - 1/2" Ball valve 2957601 From:09086
22 1 Plug ½” with seal 2957421
23 Hydraulic oil 78 litres 141201152
