DUUN VM420 - Number Index

Complete remote control of input conveyor 141209020
1 1 Handle plastic 2245062
2 2 Hexagon screw M6x50 ElZn 8.8 DIN 931 2422217
3 2 Hexagon screw M8x50 ElZn 8.8 DIN 931 2422256
4 2 Hexagon screw M10x16 ElZn 8.8 DIN 933 2422290
5 2 Hexagon screw M10x20 ElZn 8.8 DIN 933 2422295
6 2 Locking nut M6 ElZn DIN 985 2483608
7 2 Locking nut M8 ElZn DIN 985 2483609
8 4 Washer M6 ElZn DIN 125 2531039
9 4 Washer M8 ElZn DIN 125 2531047
10 3 Washer M10 ElZn DIN 125 2531060
11 4 Spring washer M10 ElZn DIN 127 2534060
12 1 Valve Locking valve pilot FC10 2955320
13 2 T hexagon nipple EVLK 10L 2957721
14 2 Hexagon nipple GEK BSP 3/8” L10 ED 2957759
15 2 Hose holder double hose 10mm/Cover plate 4251200
16 1 Bushing 1411167
17 1 Lever 14120191
18 1 Bracket 14120228
19 1 Orifice plate 14120254
20 1 Hydraulics hose ¼” L1770 2958212
21 1 Hydraulics hose ¼” L3080 2958213
22 1 Four part splitting knife 14120004
23 1 Eight part splitting knife 14120003
Spare parts catalogue
DUUN
Fire wood processor VM420
Number index Edition: 1.2009
Part no. Designation Pos. No. Ill. page Text page
70
