Technical data
Properties VM420
Net weight 875 kg
Length feeder conveyor A 2.200 mm
Length output conveyor-transporter B 4.000 mm
Sideways transporter + total 25 degrees to each side
Number of positions for transporter D 5 pcs
Total width during transport 2.550 mm
Height to work table max min F 880-960 mm
Total width assembled 30 degrees trans 6.850 mm
Depth seen from the side 1.280 mm
Velocity drive shaft 540 rpm
Connection with bolt fittings are standard Yes
Total height ready for transport E 2,550 mm
Diameter ventilation fan 254 mm
Required power PTO 540 rpm max 31 kW
Number of oil pumps 3
Length of stroke wood splitting function 40 or 60 cm
Max cutting diameter logs 42 cm
Speed splitting cycle 40 cm wood About 2 seconds at 8.5 tons
Splitting force max speed 5.5 tons
Splitting force at power drive (max power) 8.5 (11.0 tons)
Connection and de-connection of power
drive
Automatic
Drive of saw chain Hydraulic
Drive of input and output conveyor Hydraulic
Saw chain lubrication capacity container 5 litres
Saw chain lubrication Separate pump adjustable
Oil tank volume 78 litres
Splitting knife 6-splitter is standard
Hydraulic pressure 220 bar max
splitting force
180 bar cutting circuit
Accessories Art. No.
4-splitter knife 14120004
8-splitter knife 14120003
Power shaft Weasler L=860 4 piece 2962156
Remote control of input conveyor 141209020
All specifications are approximate values.
