Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141-1- Covers and log holder Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 1 Bearing point shaft 14120164
2 2 Locking screw M10x25 galvanized 8.8. 2344330
3 2 End plug Ø35 interior 2245069
4 2 Washer M10 galvanized 2531060
5 2 Hexagon nut M10 locking galv. 2483610
6 2 Bearing plastic 2245023
7 1 Sword cover 14120161 To:09105
7 1 Sword cover 14120243 From:09106
8 1 Cover centre 14120156
9 2 Bearing plastic 2245023
10 2 Hexagon nut M8 galv. 2481609
11 2 Washer M8 galvanized 2531047
12 2 Gas spring 2915111
13 2 Hexagon screw M8x25 galv.8.8 2422246
14 2 Hexagon nut M8 locking galvanized 8.8 2483609
15 1 HANDLE NO.1010 2245062
16 1 Body washer M10 galvanized 2533060
17 1 Hexagon nut M10 galv. 8.8 2481610
18 1 Damping plate 14120214 To:09086
18 1 Damping plate 14130105
19 9 Screw hexagon M6x12 with flange DIN6921 2451197
20 1 Cover right hand side 14120154
21 2 Hexagon screw M10x40 galvanized 8.8. 2422303
22 4 Washer M10 galvanized 2531060
23 4 Body washer M10 2533060
24 2 Hexagon nut M10 locking galv. 2483610
25 2 Curtain exterior 14120157 To:09086
25 2 Curtain exterior 14130106 From:09106
26 1 Curtain middle 14120155 To:09086
26 1 Curtain middle 14130113 From:09086
27 1 Hexagon screw M10x70 galvanized 8.8. 2422312
28 2 Washer 14120080
29 6 Bearing 14120168
30 1 Bushing 14120171
31 1 Hexagon screw M10x30 galvanized 8.8. 2422299
32 4 Hexagon screw M10x20 galvanized 8.8. 2422295
33 5 Spring washer M10 galv. 2534060
34 4 Washer M10 galvanized 2531060
35 1 Log holder bracket 14120167
36 1 Hexagon nut M10 galv. 2481610
37 1 Screw Unbraco cylinder head M10x35 2471301
38 1 Hexagon nut M10 locking galv. 2483610
39 1 Screw Unbraco cylinder head M12x110 2471366
40 1 Bushing 1311862
41 1 Handle plastic 4-530 Art. 17540 2245066
42 1 Hexagon nut M12 locking galv. 2483611
43 1 Log holder 14120166
44 1 Hexagon screw M10x20 galvanized 8.8. 2422295
45 1 Log holder wheel 14120181
46 1 Hexagon screw M8x25 galv.8.8 2422246
47 1 Hexagon nut M8 locking galv. 2483609
48 1 Gas spring No. 8-18 M8/M8 400N. 2915111
49 1 Hexagon nut M8 galv. 8.8 2481609
50 1 Washer M8 galvanized 2531047
43
