Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141- Transporter lower part Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 3 Locking screw M10x25 galvanized 8.8. 2344330
2 2 Screw hexagon M8x12 8.8 galv. 4242236 From:09096
3 4 Hexagon screw M10x25 galvanized 8.8. 2422297
4 2 Hexagon screw M12-75 galv. 2422362
5 1 Set screw unbraco M8x12 2473236
6 2 Hexagon nut M12 galv. 8.8 2481611
7 3 Hexagon nut M10 locking galvanized 8.8 2483610
8 2 Washer M8 galvanized 2531047 From:09096
9 7 Washer M10 galv.Zn DIN 125 2531060
10 2 Washer M12 galvanized 2531069
11 3 Washer M14 galv. 2531072
12 2 Spring washer M8 DIN 127 B galv 2534047 From:09096
13 1 Non return valve 3/8” 0.5bar 2955331 From:09046
14 1 Gerotor motor EL-R 80ccm - Ø25 2955519
15 1 Swivel nipple 90` EVWK12L 2957745
16 1 Swivel nipple 90` EVWK12L 2957745 To:09045
16 1 Swivel nipple 90` 3/8"- 3/8" 2957746 From:09046
17 1 Hexagon nipple BSP 3/8” GEK 12L 2957749 From:09046
18 1 Hexagon nipple BSP ½” ext.-R3/8u 2957763 From:09046
19 1 Hexagon nipple BSP ½” ext.-GEK12 2957766 From:09046
20 1 Hydraulic gasket 1/2” 2957861 From:09046
21 1 Hydraulic gasket 3/8” 2957890 From:09046
22 1 Lower output body 14120005
23 1 Chain wheel 5/8" Z19 Ø25.0 2964164
24 1 Locking plate 14120269 To:09085
24 1 Locking plate 14120238 From:09086
25 1 Carrier trapdoor 14120239 From:09086
26 1 Protecting plate 14120263 From:09096
27 4 Bushings 1411284
28 2 Plastic pulley 2245011
29 2 Hexagon screw M10x40 galvanized 8.8. 2422303
30 4 Hexagon screw M8x65 galv.8.8 2422260
31 4 Washer M10 galvanized 2531060
32 8 Washer M8 galvanized 2531047
33 1 Pipe continuous 14120033
34 2 Bearing plastic 2245023
35 2 Pulley holder 14120019
36 2 Hexagon nut M10 locking galv. 8.8 2483610
37 4 Hexagon nut M8 locking galvanized 8.8 2483609
38 1 Chain 5/8 2963101
Chain link 2963146
39 18 Unbraco cylinder screw M5x40 St 12.9 2471177
40 9 Carrier 1411278
41 9 Carrier plate 1411390
42 9 Nut plate 1411391
43 18 Nut locking M5 88 galv. 2471177
44 1 Chain link 5/8” chain 2050 2963146
51
