Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141- Transporter upper part Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 2 Hexagon nut M10 locking galvanized 8.8 2483610
2 2 Body washer M10 galvanized 2533060
3 2 Washer 1411531
4 2 Locking screw M10x25 galvanized 8.8. 2344330
5 1 Body lower output 14120006
6 2 Extension spring Dt5,5 di29 L200 st 2912085
7 1 Hexagon screw M12x150 galvanized 8.8. 2422370
8 2 Washer M12 galvanized 2531069
9 1 Hexagon nut M12 galv. 8.8 2481611
10 1 Spring bracket output conveyor 14120027
11 1 Washer M12 galvanized 2531069
12 1 Hexagon nut M12 galv. 2481611
13 1 Hexagon screw M10x09 galvanized 8.8. 2422315
14 1 Seeger ring A25 DIN471 2533125
15 2 Bearing 6005 2RS 2951124
16 1 Chain wheel 2964161
17 1 Seeger ring DIN 472 47x2 2553247
18 1 Bushing 14120082
19 1 Washer M10 galvanized 2531060
20 1 Hexagon nut M10 locking galvanized 8 2483610
21 1 Protecting plate 14120264 From:09096
22 2 Screw hexagon M6x10 with flange DIN6921 2451196 From:09096
53
