Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141- Splitting cradle with parts Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 1 Grease nipple straight M8 2478407
2 1 Unbraco countersunk head screw M10x50 St.10.9 2472307
3 1 Bolt 14120208
4 1 Splitter piston 14120012
5 3 Hexagon screw M10x30 galvanized 8.8. 2422299
6 6 Washer M10 galvanized 2531060
7 3 Hexagon nut M10 locking galvanized 8.8 2483610
8 1 Valve arm 14120114
9 3 Hexagon nut M10 locking A4 2483810
10 1 Slide 14120013
11 3 Unbraco cylinder screw M10x30 A4 DIN 912 2471301
12 1 Stopper plate 14120150
13 8 Washer M10 galvanized 2531060
14 4 Hexagon screw M10x35 galv. 8.8 2422301
15 4 Hexagon nut M10 locking galv. 8.8 2483610
16 1 Splitter module 14120007
17 1 Bolt with lug 14120036
18 8 Washer M10 galvanized 2531060
19 1 Hexagon screw M10x35 galvanized 8.8. 2422301
20 4 Hexagon nut M10 locking galvanized 8.8 2483610
21 3 Hexagon screw M10x25 galvanized 8.8. 2422297
22 1 Winch with brake and wire 2966105
23 1 Plate spring 14120199
24 2 Arm 14120198
25 4 Pipe split pin 6x30mm 2525209
26 4 Washer M20 galvanized 2531086
27 2 Flange bolt 14120032
28 1 Cylinder 32x20x125 H20H20 2955362
29 2 Hexagon nipple BSP ¼” GEK 10L 2957754
30 1 Lifting arm 14120136
31 1 Splitting knife 6 parts std. 14120002
32 1 Splitting knife 8 parts acc. 14120003
33 1 Splitting knife 4 parts acc. 14120004
34 1 HANDLE NO.1010 2245062
35 1 Locking lever 14120056
36 1 Pipe split pin 6x30mm 2525209
37 2 Washer M20 galvanized 2531086
38 1 Adjustment mechanism 14120058
39 2 Hexagon screw M10x45 galvanized 8.8. 2422305
40 4 Washer M10 galvanized 2531060
41 2 Hexagon nut M10 locking galvanized 8.8 2483610
42 1 Adjustment rod 14120054
43 1 Extension spring SF-DF 2x15x70 2913028
44 1 Rotating plate 14120011
45 1 End plate 1251340
46 1 Spring washer M16 DIN 127 B galv. 2534078
47 1 Screw hexagon M16x30 8.8 galv. 2422485
48 1 Taper clamping Ø8x50 2525256
49 1 Cog wheel splitter module 1411137
50 1 Locking bolt 14120105
51 1 Locking bolt 14120106
55
