Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141- Console with handle etc. Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 1 Striking-plate with tapered slot 14120158 To:09025
1 1 Striking-plate with tapered slot 14120230 From:09026
2 1 Valve panel 14120137 To:09025
2 1 Valve panel 14120229 From:09026
3 1 Symbol plate 14120189 To:09025
3 1 Symbol plate 14120231 From:09026
4 4 Pop rivet 73 AS 4-3 2511372
5 1 Valve safety valve pilot 2955323 To:09025
6 6 Hexagon nipple BSP 3/8ut-GEK10L 2957759
7 1 T hexagon nipple L10-L10/S 2957720
8 1 Joystick VM 2955450
Rubber muff; available separately 2225130
9 6 Hexagon nipple BSP 1/4”-GEK10L 2957754
10 1 T hexagon nipple L10-L10/S-L10 2957721
11 1 Plate for joystick 14120210
12 1 Valve knife lift 2955356 To:09025
12 1 Valve knife lift 2955329 From:09026
13 1 Handle (the handle follows the valve) 2245037 From:09026
14 20 Washer M6 galv. 2531039
15 4 Nut locking M6 8.8 galv. 2483608
16 2 Screw hexagon M6x55 8.8 galv. 2422219
17 12 Spring washer M6 DIN 127 B galv 2534039
18 4 Screw hexagon M6x10 8.8 galv. 2422196 To:09025
19 8 Screw hexagon M6x16 8.8 galv. 2422200
20 2 Screw hexagon M6x50 8.8 galv. 2422217 To:09025
20 2 Screw hexagon M8x60 8.8 galv. 2422259 From:09026
21 1 Stop plate 14120192
22 1 Screw hexagon M8x16 8.8 galv. 2422240
23 1 Spring washer M8 DIN 127 B galv 2534047
24 1 Washer M8 galv. 2531047
25 2 T hexagon nipple L10-L10/S-L10 2957721 From:09026
57
