Spare parts catalogue
DUUN
Fire wood processor VM420
Group: 141- Gearbox, fan, motor, and main pump Edition: 1.2009
Pos. No. Quantity Designation Part no. Comment
1 2 Hexagon nut M10 locking galv. 8.8 2483610
2 12 T hexagon nipple L10-L10L10/s. 2957720
3 2 Washer M10 galv. 2531060
4 2 Hexagon nipple BSP 3/8” 2957759
5 1 Bracket 14120176
6 2 Locking screw M10x25 galv. 8.8. 2344330
7 1 Flash fittings TE-coupling 8mm 1/8” 2957817
8 4 Hexagon screw M6x30 galv.8.8 2422209
9 8 Washer M6 galv. 2531039
10 1 Cog wheel motor Gp. 1 2955572 To:09045
10 1 Cog wheel motor Gp. 1 2955573 From:09046
11 4 Hexagon nut M6 locking galv. 8.8 2483608
12 1 Fan hub 14120062
13 1 Fan blade 4253081
14 1 Washer 14120063
15 4 Spring washer M6 galv. 2534039
16 4 Hexagon screw M6x16 galv.8.8 2422200
17 2 Hexagon screw M8x25 galv.8.8 2422246
18 1 Fixing plate for protection funnel 1312379
19 1 Protection funnel Comer 518 2962135
20 4 Hexagon screw M12x30 galv 8.8. 2422348
21 4 Spring washer M12 galv. 2534069
22 4 Washer M12 galv. 2531069
23 4 Hexagon screw M10x30 galv. 8.8. 2422299
24 4 Washer M10 galv. 2531060
25 1 Bracket 14120180
26 4 Hexagon nut M10 locking galv. 8.8 2483610
27 1 Gearbox ML52 1:3:8 (oil volume 3.5dl) 2961008
28 1 Spline coupling gearbox pump 2961200
29 2 Hexagon nipple 3/4” L-22mm 2957774
30 1 Hexagon nipple 3/8” GEK 12L 2957749
31 1 Hydraulic pump 22+22+3.1 2955555 To:09045
31 1 Cog wheel pump trip. 22+22+08 2955556 From:09046
32 1 Unbraco cylinder screw M8x25 St.12,9 2471246
33 1 Hexagon nipple BSP 3/8”-GEK10L 2957759
34 1 Spring washer M8 galv. 2534047
35 2 Hexagon nipple ½” L-15mm 2957768
36 1 Washer M8 galv. 2531047
37 2 Spring washer M8 DIN 127 B galv 2534047
38 2 Nut locking M12 8.8 galv. 2483611
39 1 Protecting plate 14120266
61
