Duux Edge - Assembly and Required Tools; 5.2.1. Required Tools

15
EN
5.2.2. Assembling the product
1. Carefully place the product on a soft, stable
and at surface.
2. Remove the rubber protection plugs 5 from
the oor stand mounting holes 6.
3. Place the rst oor stand q on the product
and align the holes on the oor stand with
the mounting holes 6.
4. Attach the rst oor stand q to the product
with the bolts r using a screwdriver.
5. Perform step 3. and 4. for the second oor
stand.
6. Put the product in an upright position on the
oor.
- The product is now ready to use.
5.2.3. Mounting the mounting bracket
NOTICE
• Never mount the product on the wall with the
oor stands placed on the product.
• Take a minimal spacing into account when
mounting the mounting bracket. See the next
image.
20
350
465
mm
435
435
820
1. Determine the desired position of the
mounting bracket e and mark the 4 holes
of the mounting bracket accordingly.
2. Drill a hole with a diameter of 6 mm at each
of the 4 marks.
3. Place a plug u into each of the drilled holes
and use a hammer to x the plug.
