Duux Edge - Wall Mounting Procedures

16
NOTICE
• Make sure that the plug is up to the sealing ring
into the hole.
4. Align the holes in the horizontal mounting
bracket e with the holes in the wall.
5. Attach the horizontal mounting bracket
e to the wall with the screws t using a
screwdriver.
6. Align the hole in the vertical mounting
bracket w with the holes in the horizontal
mounting bracket e.
7. Attach the vertical mounting bracket w to
the horizontal bracket e with a screw y
using a screwdriver.
8. Place the mounting slots 4 over the
mounting hooks of the horizontal mounting
bracket e.
- A click is heard when the mounting bracket
hooks are in the mounting slots 4.
9. Shift the product over the mounting bracket
hooks to the left until a stop is felt.
10. Shift the product downwards until a click is
heard.
- The product xates itself onto the horizontal
mounting bracket e.
NOTICE
• The product is mounted correctly if you hear a
click sound.
