DV Power RMO-H User Manual

Manual RMO-H
M-RH00NN-300-EN 7
2.1 Front Panel Components
1 – LCD Display
TFT LCD 2.8 in (43,2 mm x 57,6 mm / 1.8 in x 2.3 in)
4 – Current output terminal (–)
2 – Keyboard
Used to control the device
5 – Protective Earth Connector
Used for protection against parasitic currents or voltages
3 – Current output terminal (+)
6 – Charger Connector
7 – Connectors for the voltage sense cables
(+) Standard banana connector (red)
(–) Standard banana connector (black)
8 - Remote control connector
1
Figure 2-2:
Front panel components
Figure 2-3:
Voltage sense and remote
control connectors
2
3
4
5
6
7
8

DV Power RMO-H Specifications

General

Brand	DV Power
Model	RMO-H
Category	Measuring Instruments
Language	English
