D20, D20VSD, D20TD, D20TDVSD-C
Feb ‘14
- 3 -
Quick Start (cont’d)
Lubrication.
Rotation.
(Refer to Page 9) (Refer to Page 11)
Check the oil after
the Unit has been at
rest for a minimum
of 30 minutes.
Some Units are not equipped with an ‘Anti
Rotation’ Switch. Operating the Unit in the
reverse direction will cause irreparable
damage.
The Inverter to the Motor is pre-wired at the
factory.
Remove the Front Door and pay close
attention to the arrow located on the Motor
indicating correct rotation. Turn Unit on and
immediately turn off using the Emergency
Stop Button.
If the rotation is not correct, simply change
two of the motor leads to the Inverter.
Oil Fill Plug
