Installation – Electrical (cont’d)

Cooling Fan Rotation.

To ensure that the Unit operates at optimum

temperatures, a Cooling Fan is located on the top of

the Unit to draw warm air from the Cabinet

Enclosure. It is imperative that the Fan rotate in the

correct direction.

A label inside the Unit (as

shown at right) indicates the

proper Fan rotation.

If the Cooling Fan rotation is incorrect, switch the

incoming leads ‘L1’ and ‘L3’ to the Unit.

Wiring from

Cooling Fan
