Preventative Maintenance Schedule (cont’d)
Maintenance Item: Daily
Maintenance Interval (in 000’s of Hours)
2 4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
Compressor Room
Temperature Inspect Ambient Temperature should be between 10°C and 40°C (50°F and 104°F)
Cleanliness Inspect
Air Compressor Unit
Check Oil Level Inspect
Replace Oil # (See Note b) (1) X X X X X
Replace Oil Filter # (2) X X X X X X X X X X
Replace Air / Oil Separator # (3) X X X X X
Replace Air Intake Filter # (4) X X X X X X X X X X X X X X X X X X X X
Replace Coupling Spider* (5) X X X X X
Replace Belts** X X X X X
Replace Tank Relief Valve X X X
Replace Solenoid (6) X X X X X
Rebuild Intake Valve (7) X X X X X
Rebuild Thermo Valve (8) X X X
Rebuild Minimum Pressure Valve (9) X X X X X
Replace Scavenge Line Filter (10) X X X X X
Motor Bearing Lubrication Refer to Motor Manufacturer’s Recommendations on Page 14
*H series compressors with Variable Speed Drive
**H series fixed speed compressors
Notes: a) For Compressor Units used in an environment where the ambient temperature is above 32°C (90°F),
or b) where the Unit temperature runs regularly above 80°C (175°F), the components marked with a
‘#’ must be changed twice as often (example: in 4000 hours instead of 8000), and not as noted
above.
b) The DV Systems Oil used in the Rotary Screw Units is rated as an 8000 hour Oil. A complete Oil
change must be done every 8000 hours of Unit operation, or every 12 months, whichever occurs first.
Please refer to the Warranty on Page 28 for further information.
c) If a component, during a regular inspection, has proven to be defective or unfit for regular operation, it
must be repaired or replaced.
Parts and Repair Kits based on the above chart are as follows:
(1) Oil: DEV-3000
(2) Oil Filter DSC-624
(3) Air / Oil Separator: DSC-002051
(4) Air Intake Filter DSC-002073 + DSC-002074
(5) Coupling Spider DSC-001983
(6) Solenoid DSC-002052
(7) Intake Valve Repair Kit DSC-002075
(8) Thermo Valve Repair Kit: DSC-111-1
(9) Minimum Pressure Valve Kit: DSC-231
(10) Scavenge Line ‘In Line’ Filter DSC-612
Ambient Filter DSC-002069
As noted previously, the ‘MK-H50’ Maintenance Kit includes the following items:
(5) ‘DEV-3000’ US Gallon (5 x 3.8 litre) Oil
(2) ‘DSC-624’ Oil Filter
(1) ‘DSC-002051’ Air/Oil Separator Filter
(2) ‘DSC-002073’ Air Filter
(2) ‘DSC-002074’ Air Filter
(1) ‘DSC-612’ In Line Filter
