DVO DIAMOND - DVO Diamond Fork Disassembly; Removing Adjusters and Detents

Remove 2.5mm bolt from low speed
adjuster.
Use the 32mm socket to loosen
damper side top cap. Do not
completley unthread.
Lift the high and low speed
compression adjusters up to reveal the
detent insert.
Tip: Remove the adjusters slowly to
keep the detents from falling.
Use the 32mm socket to loosen
air side top cap. Do not
completley unthread.
Remove the two detents from the
detent insert.
Use the 18mm socket to loosen the
rebound side footnut.
1. 4.
2. 5.
3.
// pg. 1 // pg. 2
6.
