DX Engineering 5-BTV - Default Chapter; Table of Contents

- 2 -
Table of Contents
Chapter 1 - Introduction
Congratulations !
4
Over 50 Years Ago
4
Hustler
®
BTV antennas
5
You gotta be kidding me......
6
Basic Assembly and Enhanced Operating Assembly
6
Chapter 2 - General Information
Warning and Overhead Power Line Safety
7
Basic Tools Required
7
Assembly Notes
7
Chapter 3 - Common Starting Information
Installation Sequence
8
Site Selection
9
Mounting Pipe
9
Concrete or No Concrete – That is THE Question
10
Coaxial Cable to Mounting Pipe
11
Chapter 4 - Some Really Good Information
Get the Best Performance From Your New Quarter-Wave Vertical Antenna
11
Some Brief Words on Ground Mounting, Elevated Mounting, and Radial Wires
12
How to Put Radial Wires Down Without Digging
13
Radial System Considerations
14
Chapter 5 - Basic BTV Assembly
Assembling Vertical Aluminum Antenna Sections & Element Clamps
17
Hustler
®
4 BTV - Package Contents & Assembly
19
Hustler
®
5 BTV - Package Contents & Assembly
21
Six Blade Spider for the 4-BTV and 5-BTV only
23
Three Blade Spider for the 5-BTV only
23
80 Meter Resonator and Whip Installation for the 5-BTV and 6-BTV
23
Hustler
®
6 BTV - Package Contents & Assembly
24
Hustler
®
Base Assembly
26
Optional Reinforced Lower Tube Assembly
27
Mating the Vertical Sections to the Base Section
28
Installing Radials & Feedline on the Hustler® Base
29
Coax RF Choke
30
Basic Tuning
30
Chapter 6 - DX Engineering Enhanced Antenna Systems
Special Hustler
®
BTV Packages Available from DX Engineering
31
Radial Plate to Mounting Pipe
33
Attaching Ground Radial Wires to the Radial Plate
34
DXE-TB-3P Tilt Base Mounting Plate to the Ground Mounting Pipe
35
BTV Antenna Base Section to the DXE-TB-3P Tilt Base
35
Testing the DXE-TB-3P Tilt Base
36
DXE-OMNITILT-1P OMNI-TILT™ Tilt Base
37
Mounting the OMNI-TILT™ Tilt Base to the Ground Mounting Pipe
38
Mounting the Hustler BTV Base to the OMNI-TILT™ Tilt Base
39
Alternate Feedpoint Connections
40
The DXE-VFCC-H05-A Vertical Feedline Current Choke
41
