Dymax ECE Series UV Flood-Lamp Systems User Guide
Specifications
Specifications
Property
Specification
Models
ECE 2000 System
ECE 5000 System
Part #
No Power Cord*
40830
40840
Asian Version, Type G Power Cord
41060
41050
Unit Warranty
1 year from purchase; see warranty section for more information.
Flood Lamp Specs
Typical Initial Output Intensity
UVA** (320 - 390 nm)
105 mW/cm
2
225 mW/cm
2
Weight
3.4 lbs. [1.5 kg]
2.7 lbs. [1.2 kg]
Dimensions,
W x D x H
10.5" x 9.0" x 7.5"
[26.7 x 22.9 x 19.1 cm]
6.75" x 6.75" x 8.0"
[17.2 x 17.2 x 20.3 cm]
Power Supply Dimensions
(approx.), W x D x H
15.75" x 11.6" x 3.8" [39.9 cm x 29.5 cm x 9.65 cm]
Hour Meter
99,999.9 hours (non-resettable)
Electrical Power Output
400 Watts
Operating Temperature
0 to 40°C
Storage Temperature
-20 to 80°C
Operating Humidity
0-90 % (non-condensing)
Line Voltage
100 - 240 VAC +/-10% Single Phase
Line Frequency
47-63 Hz
Current Consumption (max)
@115 VAC 6.30 A
@230 VAC 3.15 A
Inrush Current (max)
12.6 A / 2.2 ms
Electrical Regulation
+/- 2.5% for effects of load, line, temperature
Power Supply Output to Lamp
VAC, 3.1A
Output Protection
Short circuit and overload protected
Auxiliary DC Outputs
+24V, 1.5A available for lamp housing fan and shutters
Bulbs
38560
36970
36658
400 watt, metal halide (standard)
400 watt, mercury vapor (optional)
400 watt, visible (optional)
Bulb Life
2,000 hours (bulb ignition only)
Certifications
RoHS compliant, CE marked
* The appropriate power cord will be added for European customers.
** Intensity readings vary widely depending on the make and model of the radiometer. These intensities were measured with the ACCU-CAL™ 50
radiometer.
