Dymo LabelWriter 450 Quick Start Guide

H-1265
PAGE 6 OF 10
1013 IH-1265
5
4. Loading Labels
To load a label roll
1 Press the form-feed button to eject the labels that
protected the printer during shipment.
2 Open the top cover and remove any packing
material inside the label compartment.
3 Remove the label spool from inside the cover.
4 Hold the spool spindle in your left hand and place the
label roll on the spindle so that the labels feed from
underneath and the left edge of the label roll is flush
against the side of the spool. See Figure 7.
5 Place the spool guide onto the right side of the spool
and press the guide tightly against the side of the
label roll, leaving no gap between the roll and the spool. See Figure 7.
NOTE The label roll must fit snugly against both sides of the
label spool, with no gaps, to avoid drifting as the labels feed
through the printer.
6 Insert the label spool into the slot in the printer cover with
the labels extending from underneath the roll. See Figure 8.
Figure 7
Spool
spindle
Spool
guide
Figure 8

Dymo LabelWriter 450 Specifications

General

Print technology	Direct thermal
Vertical printing	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Power consumption	1750 mA
Power requirements	24 VDC
Product color	Black, White

Weight and Dimensions

Depth	184 mm
Width	124 mm
Height	146 mm
Weight	680 g
