16
ASSEMBLY INSTRUCTIONS
17. Place 3 Cooking grates (H) into Grill body (C)
as illustrated in the gure. Secure Warming
rack (G) into Grill body (C).
NOTE: Insert the Warming rack (G) into the
four holes located on both sides of Grill
body (C).
17
18. Insert Grease pan (E) into position by sliding it
in the Grill Body (C) from the rear as shown,
along the rails located just below the underside
of the Grill body (C), and insert the Grease
cup (F) into position by sliding it onto the rails
on the bottom of Grease pan (E). Then insert
Side burner grease pan (O) into position by
sliding it onto the rails on the bottom of side
burner rebox.
18
G
H
E
O
F
C
C
