Dyna-Glo KFA50WH - Unpacking and Assembly

4
3. UNPACKING AND ASSEMBLY
1. REMOVE THE HEATER AND ALL PACKING MATERIALS FROM THE BOX. (Fig. 4 and 5)
NOTE : Save the shipping carton and packing materials for future storage.
Figure 4. KFA50WH/80WH MODELS
KFA50WH
KFA80WH
KFA180WH
KFA220WH
KFA135WH
Wheel Support Frame No Yes Yes
Wheel No Yes Yes
seYseYoNThreaded Axle
seYseYoNFront Handle
Rear Handle
seYseYoN
oNoNseYeldnaH
seYseYoNparW droC
Hardware kit : HW-KFA1016 No Yes Yes
Handle
Cap Nuts S
Hardware Kit : HW-KFA1016
(10" Flat Free)
Wheels
Cord Wraps
Screws
Flange Screws
Nuts
Bushings
Cap Nuts L
Axle
Rear Handle
Wheel Support Frame
Front Handle
NEVER LEAVE THE HEATER
UNATTENDED WHILE BURNING!
Figure 5. KFA135WH/180WH/220WH MODELS
